Doosan GL08K - Page 141

Maintenance - 135 -
SPLICE
R2 AEXF
0.85 RECU J2-A18
R2 AEXF
0.85 RECU J2-A19
R3 AEXF
0.85 RECU J1-B11
R4 AEXF
0.85 RECU J1-A11
B1 AEXF
0.85 BECU J1-B24
B2 AEXF
0.85 BECU J1-A24
P23
2AEXF
0.85 GECU J1-C2
AN21_ELEVATED IDLE/
PTO
3 AEXF
0.85 Lg ECU J1-B9 CAN +
4 AEXF
0.85 Lg/B ECU J1-B10 CAN -
5 AEXF
0.85 Br ECU J1-B22 SCI +
6 AEXF
0.85 Br/B ECU J1-B23 SCI -
7AEXF
0.85 G ECU J1-C5 AN23_REMOTE PTO SW
8AEXF
0.85 G ECU J1-A28 AN14_EX. BRAKE REQ
9 AEXF
0.85 P ECU J1-C17 CAN2 +
10 AEXF
0.85 P/B ECU J1-C18 CAN2 -
12 AEXF
0.85 G/Y ECU J1-A8 AN3_FPP SIGNAL
P24
1 AEXF
0.85 G/Y ECU J1-B7 DG1_IVS
2AEXF
0.85 G ECU J1-A7 AN17_OIL PRESS
3AEXF
0.85 G ECU J2-B20 LS10_FUEL GAUGE
4AEXF
0.85 G ECU J2-B6 EST13_MIL
5AEXF
0.85 G ECU J2-B17 LSO7_TLC
6AEXF
0.85 G ECU J1-C4 AN22_CLUTCH
7AEXF
0.85 G ECU J2-B8 EST16_RSG/PTO/CRU
8 AEXF
0.5 G ECU J1-A22 TACH_TACHOMETER
9AEXF
0.85 G ECU J1-C16 DG2_DOOR LOCK
10 AEXF
0.85 G ECU J1-A23 LSO3_ENGINE BRAKE
12 AEXF
0.85 G ECU J2-B7 EST15_LOW FUEL LAMP
P25
1 AEXF
0.5 R/L ECU J1-B2 KEY ON
2 AEXF
0.5 R ECU J1-B8 BATT
3 AEXF
0.85 B/G ECU J1-B18 MPRD
5 AEXF
1.25 R P40 CONN 21
P56
AAEXF
0.85 G ECU J1-A12 SPD2_VEHICLE SPEED
BAEXF
0.85 G ECU J1-A6 ANO6_BOOST PRESS
P57
A AEXF
0.85 Or ECU J1-C1 AN24_CRUISE UP
B AEXF
0.85 Or ECU J1-C3 AN24_CRUISE DOWN
C AEXF
0.85 Or ECU J1-A5 AN15_NEUTRAL
D AEXF
0.85 Or ECU J1-C12 AN26_TORQUE LIMITE
E AEXF
0.85 Or ECU J1-C10 AN18_ENABLE
F AEXF
0.85 Or ECU J1-C11 AN19_SET
P57
G AEXF
0.85 Or ECU J1-C9 AN20_BRAKE
H AEXF
0.85 Or ECU J2-B19 LSO8_FAN CLUTCH
P41 A AEXF
0.85 Br P40 CONN 1
P42 A AEXF
0.85 Br P40 CONN 5
Terminal No.
Terminal
Symbol
Wire Description
Connector
Pin no.
Signal Name
