Doosan GL08K - Page 142

Maintenance - 136 -
P43 A AEXF 0.85 Br P40 CONN 3
P44 A AEXF
0.85 Br P40 CONN 6
P45 A AEXF
0.85 Br P40 CONN 2
P46 A AEXF
0.85 Br P40 CONN 4
SPLICE R6 AEXF
0.25 R P40 CONN 21
P52
1 AEXF
0.85 R P40 CONN 10
2 AEXF
0.85 L/B P40 CONN 16
3 AEXF
0.85 B P40 CONN 9
4 AEXF
0.85 L/B P40 CONN 26
P5 B AEXF
0.85 W P63 CONN 1
P6 B AEXF
0.85 W P63 CONN 2
P7 B AEXF
0.85 W P63 CONN 3
P8 B AEXF
0.85 W P63 CONN 4
P9 B AEXF
0.85 W P63 CONN 5
P10 B AEXF
0.85 W P63 CONN 6
P11 B AEXF
0.85 W P63 CONN 7
P12 B AEXF
0.85 W P63 CONN 8
P17
B AEXF
0.85 R P63 CONN 26
C AEXF
0.85 L P63 CONN 12
P18 B AEXF
0.85 L/Y P63 CONN 14
SPLICE R2 AEXF
0.85 R P63 CONN 21
SPLICE R2 AEXF
0.85 B P63 CONN 16
Terminal No.
Terminal
Symbol
Wire Description
Connector
Pin no.
Signal Name
