Doosan GL08K - Page 143

Maintenance - 137 -
2) ECM power description
 Bus
 Truck
Signal
Name
Connector
Pin No.
Harness
Connector
Pin No.
Wire
color
Function
XDRG_A J1-B24
P16-A , P50-A ,
P61-28 , P40-8
Black
ECT, NGTP, Interconnector #7,
Ignition
XDRG_B J1-A24
P61-9
, P63-10 ,
P40-15
Black
Interconnector #7, FMV,
Ignition
DRVP
J2-A18
J2-A19
P25-F
, P63-9 Red Interconnector #6, FMV
XDRP_B J1-A11
P61-1
, P63-13 ,
P40-13
Red
Interconnector #7, FMV,
Ignition
XDRP_A J1-B11 P50-B
, P40-10 Red NGTP, Ignition
DRVG_A J2-A16
P36 Black Ground
DRVG_B J2-A24
DRVG_C J2-A15
DRVG_D J2-B9
BATT J1-B8 P25-B Red Power supply
KEY ON J1-B2 P25-A Red/light key-on
Signal
Name
Connector
Pin No.
Harness
Connector
Pin No.
Wire
color
Function
XDRG_A J1-B24
P16-A , P50-A ,
P28-4 , P32-7
Black ECT, NGTP, PTP, Throttle
XDRG_B J1-A24
P29-4
, P40-16 ,
P63-16 , P23-11
Black
MAPT, Ignition, FMV,
Interconnector #3
DRVP
J2-A18
J2-A19
P25-6
, P63-21 Red Interconnector #6, FMV
XDRP_B J1-A11
P29-2
, P40-26 ,
P23-1 , P63-26
Red
MAPT, Ignition, FMV,
Interconnector #3
XDRP_A J1-B11 P50-B
, P28-2 Red PTP, NGTP
DRVG_A J2-A16
P36 Black Ground
DRVG_B J2-A24
DRVG_C J2-A15
DRVG_D J2-B9
BATT J1-B8 P25-2 Red Power supply
KEY ON J1-B2 P25-1 Red/light key-on
