Safety Regulations & Specifications
- 13 -
1.5.2. Engine sectional view (cross)
1. Oil filter 7. Spark plug
2. Oil spray nozzle 8. Rocker arm
3. Connecting rod 9. Rocker arm bracket
4. Oil filler cap 10. Exhaust manifold
5. Idle pulley(air compressor) 11. Turbo charger
6. Ignition coil 12. Oil cooler
5
4
3
2
1
67
8
9
10
11
12
ED4OM051
