Maintenance - 54 -
3.1.31. Rocker arm
 Remove the rocker arm bracket fixing
bolts in reverse order (zigzag method)
of assembling and disassemble the
rocker arm.
 Take out the push rod upwards.
 Disassembly of rocker arm assembly
- Remove the snap ring from the both
ends of rocker arm shaft by means of
a plier.
- Remove the washer, rocker arm,
bracket and spring from the rocker
arm shaft in sequence.
- Press out the rocker arm bush.
CAUTION :
Do not perform disassembly operation
unless coolant, gas, etc. leak out.
3.1.32. Ignition coil and spark plug
 Loosen the ignition coil fixing nut, then
remove the ignition coil.
 Remove the spark plug using socket tool.
EA9M3011
EA8M3008
Ignition coil
cover
Spark plug
Ignition coil
ED4OM016
