Maintenance
- 58 -
3.1.38. Cylinder liner
Disassemble the cylinder liner with a
special tool or hand but be careful not to
generate any damage at cylinder block.
3.1.39. Cooling water chamber cover
Unscrew the fixing bolts and remove
the water chamber cover.
Remove the remnant gasket
thoroughly.
3.1.40. Fly wheel
Remove the flywheel fixing bolts and
disassemble it.
The bolt removal is done by the reverse
order of assembling and by the steps.
3.1.41. Oil seal
Diassemble the rear oil seal using an oil
seal removing jig.
