Maintenance
- 59 -
3.1.42. Fly wheel housing
Remove the flywheel housing fixing
bolts and disassemble the flywheel
housing.
3.1.43. Camshaft and tappet
In order for camshaft not to be
damaged, disassemble turning it.
In order for the disassembled camshaft
to be prevented from bends or damage,
put it on the special lathe and store.
Pull out the tappet.
As required, pull out the camshaft bush
from the cylinder block by a press.
Use a puller to remove the crankshaft
gear.
3.1.44. Timing drive gear
Unscrew the drive gear housing fixing
bolts and remove the drive gear
assembly.
3.1.45. Timing gear case
Remove the timing gear case
assembling bolts.
By tapping lightly with a urethane
hammer the right and left back of timing
gear case's connecting part,
disassemble the timing gear case.
EB8O6004
