(2) Heat the piston with a electric heater,
then take out the piston pin from the
piston as tapping it with a round
wooden bar.
(3) Remove the piston ring with a plier.
(4) Clean the piston thoroughly.
9.1.28. Cylinder liner
•
Disassemble the cylinder liner with a
special tool or hand but be careful not
to generate any damage at cylinder
block.
9.1.29. Gear and idle gear pin
•
Remove the camshaft gear assem-
bling bolts and disassemble the
camshaft gear.
- 74 -
