Dorma ES 200 - Technical Specifications and Modules; Door Parameters; Basic Module (BM); Technical Data of Operator

Basic module (BM) ES 200
Modular design
3
Microprocessor-controlled function programs
– Off
– Automatic
– Permanent Open
– Partial Open
– Exit Only
– Night-/Bank Function
3
3
3
3
3
3
Connections for – electro-mechanical locking device
– light barriers
3
3
Adjustment of all basic parameters
via integrated display and pushbuttons
3
24 V output for external accessory
3
Read-out error memory with error codes
3
DCW
®
bus interface (Protokoll DORMA Connect and Work)
3
Rechargeable battery pack for emergency operation
3
Function module (FM) – optional extra
Pharmacy Function
3
Door status contact (three)
3
Main and secondary closing edge protection
3
Panic Closing Function
3
Bell contact
3
Airlock control
3
Synchronous operation
3
DIN 18650 and EN 16005 function module – optional
The DIN 18650 and EN 16005 function module
enables the tested monitoring of the secondary closing
edges in order to comply with the German standard
DIN 18650 and EN 16005.
§
Additional equipment
Electro-mechanical locking device (bistable)
§
Manual lock release for electro-mechanical locking device
§
Light barriers
§
Rechargeable battery pack
(emergency opening, emergency closing)
§
Module for coupling to EIB or
LON building management systems
§
Infrared detector
§
3 standard § optional
Door parameters ES 200
Single-panel sliding door
– Clear passage width LW
– Door panel weight, max.
700 – 3000 mm
1 x 200 kg
Double-panel sliding door
– Clear passage width LW
– Door panel weight, max.
800 – 3000 mm
2 x 160 kg
Clear passage height* 2100 – 3200 mm
*Other dimensions on request.
Technical data of operator
Height 100 and 150 mm
Installation depth 180 mm
Opening and closing force, max. 150 N
3
Opening speed
(incremental setting)
10 – 70 cm/s
Closing speed
(incremental setting)
10 – 50 cm/s
Hold-open time 0 – 180 s
Supply voltage, frequency 230 V, 50/60 Hz
Power consumption 250 W
Class of protection IP 20
Admissible temperature - 20 – + 60 °C
Admissible humidity (relative) max. 93 %
(non condensing)
Compliant with EU
Low Voltage Directive and EMC Directive
3
Manufactured to ISO 9001
3
Environmental product declaration in
accordance with ISO 14025
Programme holder: Institute Construction
and Environment e.V.
Declaration number: EPD-DOR-2013511-E
3
DORMA
ES 200 SLIDING DOOR OPERATOR
