Our profiles for installation
heights of 100 mm and 150
mm, which are suitable for both
corridor or wall installation,
make the system suitable for all
kinds of applications.
The basic mechanical system,
with a low number of
components, is the same for
both installation heights.
Profiles for corridor installation, 100 mm Profiles for wall installation, 100 mm
1
2
3
5
4
2
3
5
4
2
3
5
1
2
3
5
Profiles for corridor installation, 150 mm Profiles for wall installation, 150 mm
Pulley with integrated locking device
and belt tensioning device
13
12
8
9
10
11
13
7
15
1 Aluminium girder (LM)
2 Basic operator profile
3 Internal cover,
100 mm or 150 mm high
4 Wall connection profile
5 Service cover bracket
