14
5
4
3
2
13
13
1
6
5
6
4 3
2
MiniDriveUnit
At the core of the ES 200
The prefabricated MiniDriveUnit
has been industrially tested with
all the requisite electrical and
electronic components, thus
greatly facilitating the assembly,
installation and maintenance of
the operator.
Components
1 MiniDriveUnit
2 Power supply unit
3 Motor
4 Decoder
5 Basic module (BM)
6 Function module (FM)
7 Track rail and mounting profile
8 Rechargeable battery pack
(optional)
9 Carrier head
10 Pulley (locking device)
11 Service cover bracket
12 End stop
13 Door connection with
adjustment device
14 Belt connection
15 Belt tensioning device
