SWITCHES
—
Designation Specification Installation system Order No.
On/Off switch White, aluminium, flush-mounting,
80 x 80 mm Gira S-Color 19135403150
Radar switch „MAGIC SWITCH”, proximity-type
radar switch responds to movement,
for flush-mounting, 80 x 80 mm 05076831332
PUSH BUTTON
—
Palm pushbutton Designation Specification Installation system Order No.
Single-pole changeover contact,
single-type frame, white,
flush-mounted version System 55 19144701170
Key switches Designation Specification Installation
system
Order No.
KT 3-1
1 NO contact with profile half-cylinder, may be replaced for any
profile half-cylinder of a master key system, key only retractable
in neutral position, aluminium, metal, 75 x 75 x 60 mm
KT 3-1 UP flush-mounted version 05054531332
KT 3-1 AP surface-mounted version 05054631332
KT 8
Lettering “Auf, Zu” (German for “Open/Closed”),
2 NO
contacts, with profile half-cylinder, may be replaced for any
profile half-cylinder of a master key system, key only retractable
in neutral position, aluminium, metal, 75 x 75 x 60 mm
KT 8 UP flush-mounted version 05054831332
KT 8 AP surface-mounted version 05054931332
TL-ST S55 Switch with single-pole changeover contact,
for profile half-cylinder by others to DIN 18252, locking cam
centre 30 – 32.5 mm, overall length 40.5 – 43,5 mm,
locking cam position left (90°), incl. cover for System 55,
not suitable for box for surface-mounting,
not including profile half-cylinder, not including frame
TL-ST S55 W White System 55 56330710
TL-ST S55 S Silver-coloured System 55 56330701
TL-ST S55 A Anthracite System 55 56330715
KT 3-2 1 NO contact with profile half-cylinder,
may be replaced for any profile half-cylinder of a master key
system, key only retractable in neutral position,
exchange cover, „Ein/Aus“ lettering (German for „On/Off“),
aluminium, flush-mounted version: 125 x 100 mm,
surface-mounted version: 70 x 90 mm 05054731332
8
