Dorma ES 68 Series - LEGO v2 installation manual__P4

—
4
560166-01140 01 / 16
ES 68 SERIES 精智系列
Single Left-Open (DW≥900mm)
PW
Single Right-Open (DW≥900mm)
(in mm)
(in mm)
L
min
= PW x 2 + 50, DW = PW + 50
L
min
= PW x 2 + 50, DW = PW + 50
50
150 320
30
DW
PW
50
150 320
DW
