Exit Device Operators 630/750/79E/RT/E7900 Series/ Generation E-730 PK3677_T 10-18 3
Each lockset for E-730/630/750/79E/E7900 includes:
(A) Outside lever handle
(B) Outside housing
(C) Gasket (when required)
(G) Exit Device (Included if ordered with lock operator)
(J) Battery holder with 3 AA batteries
Parts inside hardware bag:
(D) 1 x Spindle except for the following Exit Device which
have 3: Detex F10, Dorma F9300 and Precision21/22/
FL21/FL22
(E) 1 x Inside Adaptor Plate
(F) 3 x Mounting Screw 12-24
1
/8” Hex
(H) 2 x Pan Head Screws
1
/4” 28 X
3
/4” for Yale
2 or 4 Pan Head Screws 10-24 X
3
/4” for Detex,
Dorma, Von Duprin or 4 Flat Head screw 10-24 X
5
/8” for Precision, Arrow
(K) 1 x Spanner-head Screw
(Q) 2 or 4 Flat Washer ⁄ OD for Detex Exit Device Only
Messenger / BLE Generation includes:
(S) Double enclosure.
(T) 2 X Pan Head Screws 8-32 X
1
/2’’
Tools Required:
Safety glasses
5
/16” (7.9mm) drill bit
1
/2” (13mm) drill bit
1” (25mm) drill bit
Drill
Awl or center punch
Hammer
Rubber mallet
Small flat screwdriver
Philips #2 screwdriver
Spanner screwdriver (No 6)
1
/8” Allen key
Adjustable square
Tape measure
Pencil
Tape
Cleaning supplies
(drop cloth, vacuum)
B
A
CD
E
F
Q
G
H
G
J
K
E
S-COVER
T
S-SUPPORT
W
W
S-SCREW
Mechanical Override Models ONLY:
(L) Cylinder Cap
(M) Cylinder Plug
(N) Outside Lever Handle
(O1) Adapter
(O2) Adapter & Screw
(P) Cylinder (for 630 series lock with cylinders keyed
different ONLY)
E7900 Messeger/BLE Generation includes:
(S) Battery/Antenna enclosure with spacer.
(T1) 2x Flat Head Screws 8-32 X ⁄''
(T2) 2x Flat Head Screws 8-32 X 1 ⁄''
(P) Cylinder (for 630 series lock with cylinders keyed
different ONLY)
Mechanical Override Models ONLY
L
P
M
N
** Dorma 9100/9300/9400/9500 Series are Panic Hardware only (not fire rated)
Dorma F9100/F9300/F9400/F9500 Series are Fire Rated Hardware
