53
ED50/ED100/ED250 09-2021DL4617-003
dormakaba ED50/ED100/ED250 OHC Header
Setup and Troubleshooting Instructions
Chapter 21
Fig. 21.4.7 Brake and brake disc assemblies
Fig. 21.4.6 Brake disc assembly removed
from brake
2
5
1
1 Brake assembly
2 Brake disc
assembly
5 Motor shaft
1
2
6
6
Fig. 21.4.5 M3 x 5 SHCS
1 Brake assembly
2 Brake disc
assembly
6 M3 x 5 SHCS
.. Torque setting of M x  SHCS.
• . in-lb + . in-lb [. Nm +. Nm]
2
6
6
1
1 Brake assembly
2 Brake disc
assembly
6 M3 x 5 SHCS
Fig. 21.4.8 Brake coil wiring
43 3 64 63 62 1G 3
1G
Red
3
Blk
