dormakaba ED900 Installation Instructions – Double egress door Chapter 1
.. Installation Instructions
This manual provides installation instructions for
ED low energy swing door operators used in double
egress door installations.
.. Manual storage
This document must be kept in a secure place, and
accessible for reference as required.
If the door system should be transferred to another
facility, insure that this document is transferred as well.
.. dormakaba.com website
Manuals are available for review, download, and printing
on the dormakaba.com/us website.
.. Dimensions
Unless otherwise specified, all dimensions are given in
inches (“) and [mm].
.. Building codes and standards
ED installation: observe applicable national and local
building codes.
General information
. General information
.. Symbols used in these instructions.
WARNING
This symbol warns of hazards which could result
in personal injury or threat to health.
CAUTION
This symbol warns of a potentially unsafe
procedure or situation.
NOTICE
Draws attention to important information
presented in this document.
TIPS AND RECOMMENDATIONS
Clarifies instructions or other information
presented in this document.
.. Arm configurations.
ED is suitable for installation using the following arm
configurations:
• J – Standard push arm, - " reveal
• J – Deep reveal push arm, " - " reveal
. ED Arm configurations
• T – Arm and track, - " reveal
• T – Deep reveal arm and track, " - /" reveal
