Dormakaba GSR-EMR XEA BG Mounting Instructions

3
TS 98 XEA
mit Brandschutzplatte
with fire protection plate
2021-10
dormakaba Montageanleitung
Mounting instructions
Product description
WN 060289 45532
2.3 Basic warnings
CAUTION
Risk of injury due to improper mounting!
Incorrect mounting can cause injury.
• Use dowels and screws that are suitable
for the existing structure.
• Note the closing of the valves in Figure 6.
3 Product description
3.1 Parts included
Abb.3
1
2
3
4
Door closer with fire protection plate
(1) Fire protection plate
(2) Door closer
(3) Cover
(4) Bag of screws for door closer
3.2 Additionally required articles
Abb.4 Slide Chanel Art. No.: 570100xx
3.3 Technical data
Closing force: EN 1–6
Temperature range: 60°C to -40°C
Door width: 750 mm–1400 mm
4 Disassembly and disposal
Disassembly is carried out in reverse order
to the mounting instructions
The product contains oil and should not
be disposed of with domestic waste.
Oil must not be permitted to enter the
sewerage network.
Dispose of the product in an environmentally friendly
manner in the collection and reception centers set up
for this.
Observe the applicable national legal regulations.
