Saffire
TM
EVO Wi-Fi Lock PK519348 03-23
4
dormakaba Saffire
TM
EVO
LED indicators
Standard LED indicators
Message LED pattern
Cloud connection - Connected 1 Blue flash and 1 Green flash
Cloud connection - Disconnected 1 Blue flash and 1 Red flash
Low battery Long Red light
Credential accepted (Mobile, PIN, or RFID)
3 Green flashes
then
Battery level indicator: Cyan (BAD: battery level <3.6V)
Credential failed (Mobile, PIN, or RFID)
3 Red flashes
then
Battery level indicator: Cyan (BAD: battery level <3.6V)
Advanced LED indicators
Message LED pattern
Main board FW update in process
Solid Yellow then Yellow flashes until lock restarts
After successful FW update the lock will restart
Wi-Fi board FW update in process Blue flashes until lock restarts
Note about battery life: It is recommended to change batteries as soon as possible after a low battery indicator is displayed (Long red
light). The low battery indicator is shown when batteries are at 3.6 V. Batteries will typically last between 1-2 weeks once this indicator
is shown.
Using the Saffire EVO lock
