6 Integrated Power Reserve
module test (SVP2000F)
The internal Power Reserve module is tested 5
minutes after the power is turned on and then every
48 hours. If the test completes with an error, the
corresponding flashing code appears once according
to the error messages (see chapter 9). The test is then
performed a second time after a further 5 minutes.
If this test is also negative, the flashing code is
permanently displayed.
7 Pin assignment
7.1 SVP2000(F)
SVP-A 1100/2100 cable colors
Operation mode
DCW CAN Stand Alone
PIN 1 bk GND GND GND
PIN 2 rd - -
Unlock (1-leaf), pull
input to GND via a
switch.
PIN 3 wh +24V DC +24V DC +24V DC
PIN 4
- -
-
PIN 5 bn - -
Unlock (2-leaf), pull
input to GND via a
switch.
PIN 6 vio
Locked,
output switches to
GND
(max. 30 mA)
Locked,
output switches to
GND
(max. 30 mA)
Locked,
output switches to
GND
(max. 30 mA)
PIN 7 rd/bu - - -
PIN 8 bu - -
External door
contact, pull input
to GND via door
contact.
Door closed =
contact closed
PIN 9 gn B CANH -
PIN 10 pk/gy - - -
PIN 11 ye A CANL -
PIN 12 - - -
18
SVP/SVZ door locks
2020-03
WN 059744 45532
dormakaba Mounting instructions Integrated Power Reserve module test (SVP2000F)
