A SIMPLE METHOD
THE DOSATRON IS COMPOSED OF:
NOTA : This method of calculation cannot replace a flow meter. It is
given only as an approximate guide.
©
DOSATRON INTERNATIONAL / 23
KNOW YOUR FLOW
The speed of the motor is proportional to the flow of water passing
through the system.
Q Calculation of water flow in l/h =
Number of clicks in 15 seconds
x 4 x 60 x 0.45
Q Calculation of water flow in GPM =
Number of clicks in 15 seconds
x 4 x 0.45 ÷ 3.8
In its up and down movement, you
can hear the motor piston click:
Once in the
up position
2 clicks = 1 motor cycle
= The stroke volume
2
Calculation
for 1 hour
Calculation
for 1 minute
2 clicks = 1 cycle
Once in the
down posi-
tion
Stroke
volume in
litres
Stroke
volume in
litres
Calculation
for 1 minute
Conversion
from litres
to gallons
2
2 clicks = 1 cycle
A driving
volumetric
hydraulic
motor piston
connected
to :
a dosing
piston.
