dosatron D 25 RE 2 - Page 5

©
DOSATRON INTERNATIONAL / 3
SHIPPING CONTENTS: 1 DOSATRON / 1 mounting bracket for
DOSATRON / 1 suction tube of concentrated additive / 1 strainer /
1 injection suction tube for “IE” model / 1 owner's manual
SPECIFICATIONS
D 25 F /
D 25 F 1
D 25 F 0.2 D 25 F 2 D 25 RE 1500
Practical operating flow range: .......................................................................
Operating pressure:
bar
PSI
0.30 - 6
4.3 - 85
0.30 - 6
4.3 - 85
0.30 - 6
4.3 - 85
0.30 - 6
4.3 - 85
Externally adjustable or fixed injection rate:
%
ratio MINI
ratio MAXI
0.8 / 1
1:128 / 1:100
0.2
1: 500
2
1:50
0.07 - 0.2
1:1500
1:500
Concentrated additive injection:
MINI l/h
MAXI l/h
US Fl. oz/min-MINI
US GPM-MAXI
0.08 / 0.10
20 / 25
0.045 / 0.06
0.088 / 0.11
0.2
5
0.011
0.022
0.2
50
0.11
0.22
0.007
5
0.004
0.022
Maximum operating temperature: ...............................................................
Connections (NPT/BSP male): ........................................................................
Hydraulic motor capacity (for every 2 clicks of the piston): ............................
NOTE: The Dosatron is not preset,
UNIT SIZE
Diameter: cm
["]
12.7
5
12.7
5
12.7
5
12.7
5
Total height: cm
["]
33.9
13 3/8
31.9
12 9/16
33.9
13 3/8
39.8
15 11/16
Width: cm
["]
16
6 5/16
16
6 5/16
16
6 5/16
16
6 5/16
Weight: ± kg
[lbs]
1.0
2.2
1.0
2.2
1.0
2.2
1.2
2.7
