36 DOSATRON
The connection of the DOSATRON to the water network can be done with
flexible hoses (internal diameter 40 mm) to be fixed by means of clamps and
turning adapters Ø 40 x 49 mm [1"1/2]. Make sure the water is flowing according
to the direction arrow on the pump body.
The DOSATRON is delivered with a suction tube (cut it to the needed length)
enabling its use with a large capacity concentrate container.
The tube must be fitted with its strainer and weight.
The instructions for fitting the tube are to be found in the specific chapter.
NOTE : The maximum suction height is 4 meters [13 feet].
Fit the tube, equipped with its strainer and its weight, and immerse it in the
solution to be injected.
IMPORTANT ! - The strainer must be suspended at least 10 cm [4"]
above the bottom of the stock solution container to
avoid sucking up the insoluble particles that may
damage the injector assembly (Fig.3).
- Do not put the strainer on the ground.
WHAT YOU SHOULD DO WHAT YOU MUST NOT DO
Under no circumstance should the
solution level be above the wate
inlet of the DOSATRON.
Fig. 3
Fig. 4
10 cm [4"]
