DOSATRON 35
For connecting to polyethylene or polypropylene pipe :
- Bevel the end of the pipe and slide on nut (Fig. 2-E) and then ferrule (Fig. 2-C).
- Slide pipes into water inlet and outlet (Fig. 2) as far as they will go.
- Push one ferrule (Fig. 2-C) against the inlet and the other against the outlet.
- Tighten the nuts (Fig. 2-E).
For connecting to PVC pipe :
- Proceed as for the polyethylene and polypropylene pipes but spread PVC
adhesive on the pipe where the ferrules are to be mounted.
- Then place the ferrules over the pipe using both thumbs in the slot to widen the
ferrule (Fig. 2-C) and avoid scraping off the adhesive, then tighten the nut.
NOTA : Wait for one hour before putting into operation.
The (nut and) ferrule made of polyacetal (Fig. 2-C) will not adhere to the
PVC glue and (they) can therefore be dismantled easily at a later date.
Fig. 2
C
E
