DOTECH CX9230 Series User Manual

CX9230
Recipro/Scroll(Chiller) Controller
REV DATE
R20180403
USERS MANUAL
- 16 -
4.8 IN/OUT (CX9230-M2 Model)
15=5 Sec Delay: Output after keeping 5
secs. after comp. output
16=10Sec Delay: Output after keeping
15 secs. after comp. output
17=15Sec Delay: Output after keeping
15 secs. after comp. output
18=30Sec Delay: Output after keeping
30 secs. after comp. output
19=60Sec Delay: Output after keeping
60 secs. after comp. output
4 0157
Y1 OUTPUT MODE
0=Unuse
0
14
FREE
MASTER
0=Unuse
1=Heat: Use as heating output
2=Hotgas: Use as hotgas output
3=Cool: Use as cooling output
4=Coolgas: Use as coolgas
5=Cond: Use as condenser fan output
6=Reserv1
7=Reserv2
8=Reserv3
9=Reserv4
10=PV: Use as PV transmission output
11=B1: Use as B1 transmission output
12=B2: Use as B2 transmission output
13=B3: Use as B3 transmission output
14=B4 :Use as B4 transmission output
4 0158
Y2 OUTPUT MODE
0=Unuse
FREE
MASTER
4 0159
Y1 OUTPUT TYPE
0=4~20mA
0
2
FREE
MASTER
0=4~20mA: Forward direction output
1=20~4mA: Reverse direction output
2=SSR: SSR output
4 0160
Y2 OUTPUT TYPE
0=4~20mA
0
2
FREE
MASTER
NO
Parameter
Default
Min.
Max.
View
Access
Description
4 0151
N3:COMP2
1=Use
0
1
FREE
SERVICE
0=Unuse
1=Use
4 0152
N4:SOL2
1=Use
0
1
FREE
SERVICE
4 0153
N5:PUMP
1=Use
0
1
FREE
SERVICE
4 0154
N6:COMP1
1=Use
0
1
FREE
SERVICE
4 0155
N7:SOL1
1=Use
0
1
FREE
SERVICE
