CX9230
Recipro/Scroll(Chiller) Controller
REV DATE
R20180403
- 21 -
6.4 INPUT STATUS TRIP / ALARM STATE
6.4 INPUT STATUS STATE DATA
Address
Menu
Unit
Type
Size
(Word)
CX9230
MMI
Custom
3 0003
TRIP STATE
-
Analog
UINT 16
Refer to bit state below
Bit 0
SYSTEM FAULT
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 1
CTRL.T SENSOR
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 2
AUX.T SENSOR
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 3
DSCHG.T SENSOR
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 4
LP-PRESS. SENSOR
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 5
HP-PRESS. SENSOR
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 6
COMPRESSOR ALARM
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 7
CONDENSOR FAN
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 8
REVERSE PHASE
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 9
LOW LEVEL
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 10
NO FLOW DETECT
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 11
PUMP ALARM
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 12
LO-PRESS
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 13
HI-PRESS
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 14
FREEZE OFF
-
Digital
Bit
0 : Normal
1 : Alarm
3 0004
TRIP STATE
-
Analog
UINT 16
Refer to bit state below
Bit 0
LO-TEMP ALARM
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 1
HI-TEMP ALARM
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 2
DSCHG LO-TEMP
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 3
DSCHG HI-TEMP
-
Digital
Bit
0 : Normal
1 : Alarm
3 0005
ALARM STATE
-
Analog
UINT 16
Refer to bit state below
Bit 0
SENSOR CHECK
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 1
SAFETY PARTS
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 2
ELECTRIC PARTS
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 3
COMPRESSOR PARTS
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 4
REFERIGERANT
-
Digital
Bit
0 : Normal
1 : Alarm
Bit 5
OVERHAUL
-
Digital
Bit
0 : Normal
1 : Alarm
Address
Menu
Unit
Type
Size
(Word)
CX9230
MMI
Custom
3 0001
Digital Input Port State
-
Analog
UINT 16
3 0002
Digital Output Port State
-
Analog
UINT 16
3 0003
Trip State High
-
Analog
UINT 16
3 0004
Trip State Low
-
Analog
UINT 16
3 0005
Alarm State High
-
Analog
UINT 16
3 0011
Current Temp.
Analog
INT 16
-40.5 ~ 105.0
X 10
3 0012
Current Low Press.
bar
Analog
INT 16
-1.0 ~ 15.0
X 10
