DOTECH CX9230 Series User Manual

CX9230
Recipro/Scroll(Chiller) Controller
REV DATE
R20180403
USERS MANUAL
- 15 -
4.8 IN/OUT
NO
Parameter
Default
Min.
Max.
View
Access
Description
4 0141
ID1: COMP ALARM
2=N.Close
0
2
FREE
SERVICE
0=Unuse
1=N.Open
2=N.Close
4 0142
ID2: CONDENSOR AL
2=N.Close
0
2
FREE
SERVICE
4 0143
ID3: REVERSE PHASE
2=N.Close
0
2
FREE
SERVICE
4 0144
ID4: LOW LEVEL
2=N.Close
0
2
FREE
SERVICE
4 0145
ID5: FLOW SWITCH
2=N.Close
0
2
FREE
SERVICE
4 0146
ID6: PUMP ALARM
2=N.Close
0
2
FREE
SERVICE
4 0147
ID7: FREEZE HEAT
2=N.Close
0
2
FREE
SERVICE
4 0148
ID8: RUN/STOP
1=N.Open
0
2
FREE
SERVICE
4 0149
N1:HEAT OUTPUT
2=Hotgas(PID)
0
4
FREE
SERVICE
0=Unuse,
1=Heat(PID)
2=Hotgas(PID)
3=Heat(Hys)
4=Hotgas(Hys)
4 0150
N2:COOL OUTPUT
2=Coolgas(PID)
0
4
FREE
SERVICE
0=Unuse,
1=Cool(PID)
2=Coolgas(PID)
3=Cool(Hys)
4=Coolgas(Hys)
4 0151
N3:COND OUTPUT
1=Use
0
1
FREE
SERVICE
0=Unuse, 1=Use
4 0152
N4:LINJ OUTPUT
1=Use
0
1
FREE
SERVICE
0=Unuse, 1=Use
4 0153
N5:PUMP OUTPUT
1=Use
0
1
FREE
SERVICE
0=Unuse, 1=Use
4 0154
N6:COMP OUTPUT
1=Use
0
1
FREE
SERVICE
0=Unuse, 1=Use
4 0155
N7:SOL OUTPUT
1=Use
0
1
FREE
SERVICE
0=Unuse, 1=Use
4 0156
N8:AUX OUTPUT
1=Alarm
0
4
FREE
SERVICE
0=Unuse
1=Alarm
2=Trip
3=Shutdown
4=Maintenance
5=All Alarm: Output if there is any
alarm or trip occur
6=!Alarm: Output if it is not an alarm
status
7=!Trip: Output if it is not a trip status
8=!Shutdown: Output if it is not a
shutdown status
9=!Maintenance: Output if it is not a
maintenance status
10=!All-Alarm: Output if there is no
alarm
11=Run-State
12=Stop-State
13=Pump-Run
14=Comp-Run
