DOTECH CX9230 Series User Manual

CX9230
Recipro/Scroll(Chiller) Controller
REV DATE
R20180403
USERS MANUAL
- 4 -
1.5 Ordering Guide
CX9230 series
CX9230-L1
CX9230-L
CX9230-M
CX9230-V
Power
24Vac, 50/60Hz
Power Consumption
Max. 600mA@ 24Vac
Digital
Input
Opto-Isolation 8P (1P Common)
Output
Relay output 4P
Relay output 8P
Analog
Input
Temp. sensor 2P, 4~20mA 2P
Output
-
-
-
4~20mA 2P
RTC (Real Time Clock)
-
O
O
O
PID Control Logic
-
-
O
O
Communication
-
-
-
MODBUS RTU /
RS485
Connection
Screw Terminal
LCD
WIDE LCD (128x64) / TACT BUTTON TYPE
Operation Temp.
Temp. -10~50℃ Humidity under 90%RH
Storage Temp.
Temp. -20~60℃ Humidity under 90%RH

DOTECH CX9230 Series Specifications

General

Brand	DOTECH
Model	CX9230 Series
Category	Controller
Language	English
