DOTECH CX9230 Series User Manual

CX9230
Recipro/Scroll(Chiller) Controller
REV DATE
R20180403
USERS MANUAL
- 9 -
3.TRIP MESSAGE
3.1 TRIP MESSAGE
No.
Alarm
Remarks
1
SYSTEM FAULT
Please request a warranty to DOTECH INC.
2
CTRL.T SENSOR
In case of occurrence of error on CTRL.T SENSOR(B1)
(Disconnection / Short)
3
AUX.T SENSOR
In case of occurrence of error on AUX.T SENSOR(B2)
(Disconnection / Short)
4
DSCHG.T SENSOR
In case of occurrence of error on DSCHG.T SENSOR(B2)
(Disconnection / Short)
5
LP-PRESS. SENSOR
In case of occurrence of error on LP-PRESS.SENSOR(B4)
(Disconnection / Short)
6
HP-PRESS. SENSOR
In case of occurrence of error on HP-PRESS.SENSOR(B5)
(Disconnection / Short)
7
COMPRESSOR ALARM
In case of occurrence of alarm on ID1
8
CONDENSOR FAN
In case of occurrence of alarm on ID2
9
REVERSE PHASE
In case of occurrence of alarm on ID3
10
LOW LEVEL
In case of occurrence of alarm on ID4
11
NO FLOW DETECT
In case of occurrence of alarm on ID5
12
PUMP ALARM
In case of occurrence of alarm on ID6
13
LO-PRESS
In case of occurrence of error on LO-PRESS(B4)
(Disconnection / Short)
14
HI-PRESS
In case of occurrence of error on HI-PRESS(B5)
(Disconnection / Short)
15
FREEZE OFF
In case of occurrence of alarm on ID7
16
LO-TEMP ALARM
B1 Temp. < [ALARM: LO-TEMP ALARM]
17
HI-TEMP ALARM
B1 Temp. > [ALARM: HI-TEMP ALARM]
18
DSCHG LO-TEMP
B2 Temp. < [TRIP: DSCHG LO-TEMP]
19
DSCHG HI-TEMP
B2 Temp. > [TRIP: DSCHG HI-TEMP]
20
LP-PRESS. HI
B4 Press. > [ALARM: LP-PRESS. HI]
21
HP-PRESS.LO
B5 Press. < [ALARM: HP-PRESS.LO]
22
SENSOR CHECK
In case of exceeding of time on [MAINTENANCE: SENSOR CHECK]
23
SAFETY PARTS
In case of exceeding of time on [MAINTENANCE: SAFETY PARTS]
24
ELECTRIC PARTS
In case of exceeding of time on [MAINTENANCE: ELECTRIC PARTS]
25
COMPRESSOR PARTS
In case of exceeding of time on [MAINTENANC: COMPRESSOR PARTS]
26
REFERIGERANT
In case of exceeding of time on [MAINTENANCE: REFERIGERANT]
27
OVERHAUL
In case of exceeding of time on [MAINTENANCE: OVERHAUL]
