D.4 Adjusng Core Length Bar
Do not perform any installation while the main switch is on.
The core length bar (11) slides to allow seng the core length. It is provided with a rule and is
locked with lever 10. The stop (12) is located on the right and should be ipped out of the way
before the cut is made to prevent jamming the cut core.
