E. PRODUCT SPECIFICATIONS
E.1 Technical Specicaons
Do not exceed the operatng parameters of the core cutter as listed here. This will
void the machine guarantee and could cause injury.
The M70, M80 and M100 core cuers designed for dust-free manual core cung
of cardboard cores and so plasc cores tested and approved by Double E. It uses
circumferenal propulsion to cut cores; the circular knife is staonary while pressing against a
core and then it is cut.
This machine is designed only for industrial use only. Do not operate in an unvenlated area.
TECHNICAL DATA
Length 75, 85, or 105 Inches
Width 19 Inches
Height (xed part) 55 Inches
Weight 275 Pounds
Supply Voltage 110 or 220 VAC (see nameplate)
Control Voltage 24 VDC
Frequency 50/60 Hz.
Installed Power 1 HP
Motor-Single Phase Asychronous 1100 RPM
Cung material: cardboard cores with inner diameters from 3.0” to 6.0” with a maximum wall
thickness of 1/2”.
Maximum length of cut cores: 70”, 80”, 100” depending on model.
