IV. Core is not in proper contact with the drive rollers

Possible Causes:

1. The core bar assembly of the core cuer is not parallel to the machine frame

How to Proceed:

Loosen the core bar assembly fastener and adjust to a level posion, placing it in parallel to the

machine frame, ghten fastener.

This

operaon should be carried out with a core placed on the

machine.

As a result the core slides on the drive rollers. Aer cung a core, a secon of the original core stays on the

machine

and

moves to the right or to the

le.
