Dover MagLink LX4 User Manual

Element Description
USB
For USB printer connection. It can also be used for firmware updates and back-up of the console (Refer to the
M2052-EU MagLinkLX4 User Manual)
RJ45
For console configuration, and local network connections (Refer to the M2051-EU MagLink LX4 Configuration
Manual )
RS232
Com 1
Serial port for connection to management systems (FCC/POS/DCD)
RS232
Com 2
Serial port for connection to management systems (FCC/POS/DCD)
Ground
connection
Ground connection of the internal Intrinsically Safe barrier. Use a dedicated 4.0 mm
2
copper cable to connect to
the main ground lug in the electrical panel of the station. This will prevent high voltages sent to the Intrinsically
Safe wiring side if there is an electrical fault in the power side.
