A-9
TIMER PROGRAMMING INSTRUCTIONS (GRASSLIN DIGI20E-120)
The circular keypads are positioned to provide a sequential path for programming.
Starting with Prog to select a program and then HAND to select heating (ON) or cooling (OFF).
Then press h for hour, m for minute and finally Day to select day or days of the week.
If an input is missing or incomplete, the missing segments will flash when the or Prog key is
depressed. For example, if no "ON" or "OFF" is selected, the "ON" symbol will flash.
The missing entry must be completed before programming can resume.
While programming, pressing the
h, m, or Day key longer than 2 seconds will cause a rapid roll of the
parameter.
A program consists of
1. Press
Prog key
2. Select "ON " or "OFF"
3. Set hour and minute
4. Set day or multiple days on which it is to occur
Note: The program have to be coherent. So it is recommended to use Res to reset the program before
doing any important modification to the program in a way to avoid conflict between the different
programs.
A flashing display indicates either incomplete data entry or the battery is low (more than 5 days).
The ±1h key sets clock time up or down 1 hour for daylight savings time adjustment in the spring and
fall.
SETTING TIME AND DAY OF CLOCK.
1. Select the cycle of 12:00 hours or 24 hours.
2. Depress and hold
h key while pressing ±1h key to toggle between one or the other cycle and from
AM to PM.
3. Press and hold down key.
4. If setting the time when daylight savings time is in effect, press ±1h key once.
5. Set hour with h key and if AM or PM does not appear in display, it’s a cycle of 24 hours.
6. Set minutes with m key.
7. Press Day key repeatedly to the day of the week (1 is Monday, 7 is Sunday).
8. Release key.
