Doyon JA4 - Page 56

G3
OVEN
VALVE
STEAM TIMER H3DE
THERMOSTAT
HIGH
LIMIT
OVEN
SWITCH
HIGH
LIMIT
110°F
HIGH
LIMIT
140°F
COOKING
SWITCH
3/4 HP
MOTOR
DOOR
SWITCH
ELECTRONIC
TIMER
FAN
P.L.
BUZZER
(ALARM)
N1
MODE E
TV
B1 15
A2
18
A1
BUZZER
VL
C1
9 10
7 8
HL1
43
1
2
21 22
21 22
A2A1
A2A1
AR
AV
AR
AV
T5
T4
T1
T8
T3T2
L3 T3
L3 T3
AR
L1 T1
L2 T2
VA
ST
C1
VA
ST
OL1
L2L1N
OL1
95 96
BULB
F2
F1
AV
L3 T3
L2 T2
L1 T1
L2 T2
L1 T1
C1
A2A1
5 A.
7
8
6
2
M
4
1
COOKING TIMER
H5CX (MODE A−1)
L3
C1
C1
C1
ELEMENTS
2.5 KW
EACH
JA4 3 PHASES 60 Hz
23/08/04 M. FAUCHER 1
2 & 5
STANDARD
JA4_3A
1 / 1
120 / 208 0.8A 22A 21A 21A
120 / 240 0.8A 19A 18A 18
608.0 KW HzTOTAL POWER:
WARNING
FOR SUPPLY SYSTEMS CONSISTING OF A DELTA
SECONDARY TRANSFORMER, MAKE SURE THAT
THE PHASE FEEDER WITH THE HIGHEST VOLTAGE
(HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY
BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS).
