28 DR

11.5 CHIPPER SHREDDER

Chapter 6: Parts Lists and Schematic Diagrams

Parts List – Hopper, Chute and Discharge

Note: Part numbers listed are available through DR Power Equipment.

Ref# Part# Description

1 11076 Nut, Nylon Lock, 5/16-18, ZP

2 39283 Label, Danger, Discharge

3 38640 Bolt, HCS, 5/16-18 X 6", GR5, ZP

4 36521 Bolt, Hex Flange, 1/4-20 X 5/8", GR5, ZP

5 33331 Nut, Nylon Lock, Flanged, 1/4-20

6 38671 Chute w/Labels, Chipper

7 38648 Guard, Chipper

8 38647 Plate, Guard

Ref# Part# Description

9 39282 Label, Danger, Safety

10 34141 Label, DR Logo, 5.75" Silver

11 38676 Hopper w/Labels, Shredder

12 36525 Guard, Shredder

13 36544 Support, Guard, Hopper

14 36526 Support, Hopper Guard

15 36515 Plate, Blowback

16 38656 Deflector, Discharge
