32 DR
®
11.5 CHIPPER SHREDDER
Parts List – Cutting Chamber
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 11076 Nut, Nylon Lock, 5/16-18, ZP
2 38669 Label, Screen Bolt
3 39283 Label, Danger, Discharge
4 34140 Label, DR Logo, 4" Silver
5 38640 Bolt, HCS, 5/16-18 X 6", GR5, ZP
6 38650 Bolt, HCS, 5/16-18 X 6.5", GR5, ZP
7 38632 Sideplate, Drive Side
8 38631 Sideplate, Chipper Side
9 38633 Scroll, Housing
10 38634 Housing, Top Scroll
11 38654 Bolt, Carr, 1/2-13 X 1-1/2", GR5, ZP
12 11072 Nut, Nylon Lock, 1/2-13,GR5,ZP
13 25631 Bearing, Flange, 1-3/16"
14 38655 Spacer, 1.190" X 1.62" X .062", ZP
15 18301 Ring, Retaining, 1-3/16"
16 38635 Flywheel, Balanced W/Knife
17 38651 Pulley, V-Belt, 4.75" OD
Ref# Part# Description
18 38663 Bolt, SHCS, 5/16-18 X 5/8", ZP
19 38646 Screen, 1" Holes
20 37307 Hammer, J
21 37306 Hammer, Flat
22 38637 Shaft, Hammer
23 38638 Spacer, Hammer, .865" Long
24 38639 Spacer, Hammer, .865" Long W/Hole
25 36510 Bolt, SHCS, 10-24 X 1.12", Alloy Blk
26 11873 Nut, Nylon Lock 10-24
27 11173 Bolt, Hex, 5/16-18 X .5", Trilobe
28 38641 Plate, Knife Access
29 38642 Plate, Hammer Shaft Access
30 16513 Bolt, HCS, 3/8-24 X 1-1/4", GR8
W/Patch
31 14229 Key, .25" X 1.25"
32 22887 Washer, .385" ID, 1.5" OD, .25"L, ZP
Not Shown
40524 Kit, Knife, 11.5 CS3
