30 DR
®
11.5 CHIPPER SHREDDER
Parts List – Drive Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 13443 Bolt, HCS, 5/16-18 X 1-1/2", GR5, ZP
2 11076 Nut, Nylon Lock, 5/16-18, ZP
3 15488 Nut, Push Cap, 5/8", Black
4 38629 Base, 11.5
5 38630 Support, Base
6 38644 Axle
7 36498 Spacer, Wheel
8 36520 Wheel, 9" X 3.5"
9 12321 Bolt, HCS, 5/16-18 X 3/4, GR5, ZP
10 11173 Bolt, Hex, 5/16-18 X .5", Trilobe
11 13758 Label, Check Oil, 2.75" X .63"
12 18887 Label, Hot Surface
13 11241 Washer, Flat, 5/16", USS, ZP
14 11250 Washer, Lock, 1/4", Ext Tooth (E/S only)
15 11069 Nut, Hex, 5/16-18, GR2 (E/S only)
16 38664 Bolt, Hex, 5/16-18 X 1-1/2", Tri, Ft
17 38643 Bracket, Belt Tension
18 38661 Engine, 11.50 B&S, E/S
38660 Engine, 11.50 B&S, M/S
19 27901 Washer, Flat, .385" X 1.25" X .25", ZP
Ref# Part# Description
20 16513 Bolt, HCS, 3/8-24 X 1-1/4", GR8
W/Patch
21 14229 Key, Square, 1/4" X 1-1/4"
22 38657 Spacer, Clutch, .73" Long
23 38652 Belt, V, B27, Corded, Raw Edge
24 38961 Clutch, Centrifugal, 1" Bore, 4" OD
25 38653 Cover, Belt
26 11983 Bolt, HCS, 1/4-20 X 3/4", GR2, ZP (E/S
only)
27 11073 Nut, Nylon Lock, 1/4-20, ZP (E/S only)
28 13447 Battery, 12v, 9Ah (E/S only)
29 25862 Bracket, Battery (E/S only)
30 28697 Pad, Battery 2.5" X 6.12" (E/S only)
31 24230 Strap, Battery (E/S only)
32 38667 Wire Harness, Battery (E/S only)
33 29487 Boot, Terminal, Red (E/S only)
34 37340 Cable Clamp, 5/16", Nylon (E/S only)
35 31283 Nut, Lock, 1/4-20, Serrated Flange (E/S
only)
36 11170 Screw, 10-32 X 1/2", Type F, Hex, ZP
(E/S only)
To Next Page
