DR 11.5 Chipper Shredder User Manual

8 DR
®
11.5 CHIPPER SHREDDER
Figure 2
Chapter 2: Setting Up The DR 11.5 CHIPPER SHREDDER
It may be helpful to familiarize yourself with the controls and features of your DR 11.5 CHIPPER SHREDDER as shown in Figure 2
before beginning these procedures. If you have any questions at all, please feel free to contact us at www.DRpower.com.
DR 11.5 CHIPPER SHREDDER Controls and Features
Pneumatic
Tire
s
Chipper Chute
Shredder
Hopper
11.5 FT-LBS Torque
Briggs & Stratton Engine
Starter Handle
Fuel Shut-Off Valve
Choke
Control
Lever
Throttle
Fuel Fil
l
Oil Drain
(Front of Engine Base)
Oil Fil
l
Muffle
r
A
ir Filte
r
Battery
Key Switch
Electric Start Model
Belt Cover
Discharge
Deflector
Hammer Shaft
A
ccess Plate
Chipper Knife
A
ccess Plate
(Located on
Chipper Side
Sideplate)
