CONTACT US AT www.DRpower.com 7
Left
Brake/Steering
Lever
Fuel Tank
Brush Bar
Brush Blade
(Under Deck)
Brush Deck
Fuel Filter
Oil Fill/
Dipstick
Oil Drain
ON
OFF
20 hp Shown (14.5
hp and 16.5 hp
Engines Similar)
Muffler
Oil Filter
Right
Brake/Steering
Lever
Fuel Fill
Belt Guard
Traction
Drive
Lever
Operator Presence
Control Lever
Throttle Lever
Key
Switch
PTO Knob
(Blade On/Off)
Wheel Speed
Lever
Control Panel
Chapter 2: Setting Up the DR FIELD and BRUSH MOWER
It may be helpful to familiarize yourself with the controls and features of your DR FIELD and BRUSH MOWER as shown in Figure
2 before beginning these procedures. If you have any questions at all, please feel free to contact us at www.DRpower.com.
DR FIELD and BRUSH MOWER Controls and Features
10.5 hp Engine
Muffler
Fuel Fill
Pull Start
Handle
Figure 2
Fuel Shut-Off Valve
