contact us at www.DRpower.com 29
Parts List
Note: Part numbers listed are available through DR Power Equipment. Not all parts appear on all diagrams.
Ref# Part# Description
1 41522 Gear Box Assembly
2 41686 Bolt M8X20
3 41523 Flat Washer 8
37 41524 Flange Lock Nut M8
63 41525 Engine Shaft Washer
64 41526 Lock Nut M10
65 41527 Counterweight 2
66 41528 Gear Cover Mount Bracket
67 33787 Clip 1.8
68 41529 Right Wheel Assy.
69 41530 Pin Shaft B8x45
70 30250 Flat Washer 10
71 41531 Direction Indicator Weldment
72 41532 Shift Rod
73 41533 Spring Pin 5x30
74 41534 Gear Shift Markable Plate
75 41535 Bolt M6x16
76 41536 Engine
77 41537 Pulley
78 41538 Key B5x4.76x40
79 41539 Screw M8x12
80 41540 Blade Mount Bracket
81 41541 Pin B10x45
82 41542 R Clip 2.5
83 41543 Bolt M10x30
84 41544 Blade 2
85 41545 Swing Nut
86 41546 Adjustable Side Shield B1
87 41547 Bolt M8x20
88 41548 Side Tine Shield
89 41549 B Style Sprig Nut M8
90 41550 Blade 1
91 41551 Lock Nut M8
92 41552 Bolt M8x25
93 41553 Tine Shield
94 41554 Spring
95 41555 Pin
96 41556 C-Clip
97 41557 Handle Mount Bracket 2
98 41558 Handle Mount Bracket 1
99 41559 Handle Support Frame
100 41560 Bolt M10x25
101 41561 Nut M8
102 41562 Upper Handle
103 41563 Lock Lever
104 41564 Lever Knob
105 41565 Bolt M8x85
106 41566 Throttle Cable
107 41567 Throttle Lever Assy.
108 41568 Screw M6x50
109 41569 Lock Nut M6
110 41570 Tensioner Pulley Cable
111 41571 Pulley Cable Drag Rod
Ref# Part# Description
113 41573 End Cap 25
114 41574 Upper Handle Sleeve
115 41575 Brake Connecting Plate
116 41576 Shift Lever Knob
117 41577 Shift Lever
118 41578 Bushing
119 41579 Support Sleeve
120 41580 Bolt M8x75
121 41581 Spring
122 41582 Pin Bracket
123 41583 Rubber Cap
124 41584 Serrated Rear Shield
125 41585 Hinge
126 41586 Hinge Shaft
127 41587 Limiter Pin
128 41588 Spring Washer 5
129 41589 Bolt
130 41590 Adjustable Side Shield B2
131 41591 Bolt M10x25
132 41592 Spacer 3
133 41593 Screw M5x10
134 41594 Bolt M5x12
135 41595 Long Bolt
136 41596 Cable Fixation Clamp
137 41597 Belt Cover Mount Bracket
138 41598 Belt Pulley
139 41599 Lock Nut M5
140 41600 Key A5x20
141 41601 Depth Stake 3
142 41602 Belt 4LXP1308
143 41603 Depth Stake 2
144 41604 Belt Cover
145 41605 Left Wheel Assy.
146 41606 Spacer 2
147 41607 Flange Lock Nut 10
148 41608 C-Clip 9
149 41609 Tensioner Pulley
150 41610 Bushing
151 41611 Wheel Bracket Weldment
152 41612 Bolt 5/16 - 24 UNF*25
153 41613 Spring Washer 8
154 41614 Bolt M10x290
155 41615 Counterweight 1
156 41616 Bolt M8x40
157 41617 Spacer 1
158 41618 Tensioner Pulley Shaft
159 41619 Bolt M8x30
160 41620 Belt Block Rod
161 41621 Big Flat Washer 8
162 41622 Engine Protector Weldment
163 41623 Spacer 4
164 41624 Bolt M8x16
165 41625 Bearing 6004-2RS
