22 DR
®
PILOT TRIMMER/MOWER
Chapter 6: Parts Lists and Schematic Diagrams
Parts List – Main Frame Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 A0000115854 Frame, Trimmer w/Labels
2 A0000116959 Electric Powerhead w/Label, 62V,
850W
3 302451 Bolt, HHCS, M8-1.25 X 30, CLASS8
ZP
4 333421 Nut, Nylon Lock, Flanged, M8-1.25,
CL8, ZP
5 111551 Bolt, HCS, 3/8-24 X .75", ZP
6 311171 Bolt, HWH, 1/4 - 20 x .75", Taptite
7 126971 Washer, Fender 1/4" ID X 1" OD, ZP
8 310871 Pulley, Drive, 3L V-Belt, 7/8" Shaft
9 310941 Pulley, Drive, 3L V-Belt, .67" Shaft
10 119141 Key, Sq, 3/16" X 3/4"
11 A0000115855 Guard w/Labels, Trimmer, 18"
12 112381 Washer, Flat, 1/4"
13 136491 Label, Danger
14 148231 Label, Safety Icons
15 344031 Adapter, Cord Plate
16 341391 Label, DR Logo,4" Black
17 343881 Quick Lock
18 376251 Guard, Debris
19 310981 Can, Anti-Wrap
20 310991 Spacer, .680" X .984" X .310", ZP
21 311011 Mow Ball, Hex Recess
22 313011 Bolt, 3/8-16 X 1", GR5, ZP, High Hd
23 10000045280 Spacer, 2-Line Quick Lock Head
24 10000044511 Cord Pack, 11", 48 Pcs
Ref# Part# Description
25 376241 Spindle
26 335781 Cover, Spindle
27 323421 Screw, 10-14 X 5/8", Plastite, 48-2
28 123361 Bolt, HCS, 5/16-18 X 1-1/4", GR5, ZP
29 143601 Standoff, Clutch Arm
30 110761 Nut, Nylon Lock, 5/16-18, ZP
31 376071 Arm, Idler
32 376081 Spacer, .385" X .62" X .66"
33 310921 Pulley, Idler, 3L V-Belt, 2.0" OD
34 376091 Belt, V, 3L440R
35 335951 Spring, E, .5" OD, .063" Wire, 2.0"L,
ZP
36 143751 Washer, .505" ID X 1.0" OD, Plastic
37 110751 Nut, Nylon Lock 3/8-16, ZP
Not Shown
A0000057739 Label, Safety, 62V Powerhead
414241 DR 62V 5AH Battery
414221 DR 62V 5AH Battery Charger
420621 Screw, Tapping, Hexalobular Socket
Pan Head
A0000115848 Lid, Battery Cover, Powerhead
A0000115849 Cover, Wire Port, Right Powerhead
A0000115850 Cover, Wire Port, Left Powerhead
A0000115851 Gasket, Wire Harness, w/Hole
A0000115852 Gasket, Wire Harness, no Hole
A0000115853 Key, With Rope Tether, Powerhead
To Next Page
