24 DR
®
PILOT TRIMMER/MOWER
Parts List – Handlebar and Axle Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 311171 Bolt, HWH, 1/4 - 20 X .75", Taptite
2 311071 Axle, Welded
3 311081 Wheel, 14", 5 Spoke
4 152331 Nut, Nylon Lock, 7/16-20, Low Profile
5 311101 Handlebar, Lower
6 311121 Knob, 2.25" Dia, 5/16-18 Insert
7 144641 Bolt, C-Hd, 5/16-18 X 3.0"
8 311161 Screw, HWH, 5/16-18 X 3/4", Taptite
9 191351 Adjuster, Handlebar, Inside
10 143731 Adjuster, Handlebar, Outside
Ref# Part# Description
11 143931 Spring, C, .75OD, .063 Wire, .63L, ZP
12 420911 Wire Clamp
13 10000045939 Handlebar, Assembly
14 A0000115845 Bail Bar, Ergonomic
15 A0000115844 Bail Bar Housing and Return Spring
Assembly
16 A0000115846 Handlebar w/Foam
17 A0000116176 Pin, Cotter, 1 mm X 25 mm ZP
18 A0000115842 Switch Box Assembly w/ Wire
Harness
