Dräger Alcotest 9510 Standard IR

Transport
Dräger Alcotest 9510 Standard IR / EC 27
9 Transport
 During instrument transport adhere to the usual
precautions for the transport of sensitive electronic
devices.
 Avoid excessive mechanical strain, shocks, and vibrations
when transporting the instrument.
10 Storage
 Store the instrument in dry rooms. Ambient conditions for
storage, see chapter 12 on page 27.
11 Disposal
12 Technical data
This product must not be disposed of as household
waste. It is therefore marked with the adjacent symbol.
You can return this product to Dräger free of charge.
For information please contact the national marketing
organizations or Dräger.
Ambient conditions
Operation
Temperature range 0°C to +40°C
Humidity 30 to 90 % relative humidity
Ambient pressure 850 to 1060 hPa
Height limit for operation max. 3000 m
Storage
Temperature range –20 to 70 °C (>40 °C for a few
hours only)
Humidity 10 to 90 % relative humidity
Ambient pressure 700 to 1300 hPa
Measuring system
Measuring range
Breath alcohol concentration 0 to 3 mg/L
0 to 300 µg/100 mL
0 to 3000 µg/L
(Ethanol mass per breath
volume at 34 °C and
1013 hPa)
Blood alcohol concentration 0 to 6 ‰
0 to 6 g/L
0 to 0.6 %
(Ethanol mass per blood
volume at 20 °C and
1013 hPa. When providing this
data, a conversion factor of
2100 between the breath and
blood alcohol concentration is
used.)
Resolution of the final result
(in normal operating mode)
0.01 mg/L
1 µg/100 mL
10 µg/L
0.01 ‰
0.01 g/L
0.001 %
Duration of a measurement
(typical)
3 minutes
Breath time >3 seconds
Respiratory volume >1.5 L
Repeat precision: Standard deviation
0 to 0.4 mg/L < 0.007 mg/L
greater than 0.4 to
2.0 mg/L
less than 1.75 % relative
greater than 2.0 mg/L less than 6 % relative
Calibration interval recommended: 6 months;
maximum: 12 months
Typical
operating data
Supply voltage
Mains operation 110 to 240V, 50 to 60Hz
12 V operation 10.5 to 15.5 V DC
Power consumption
During
warm-up phase
approx. 70W
in standby mode <15 W
Main fuse TH/250 V; 0.63 A, 2 pieces
Thermal printer Thermal printer with special
paper, 58 mm wide
Date and time Day/month/year (selectable
date format)
Hour: Minute
Summer time/winter time
Warm-up phase less than 15 minutes at room
temperature
approx. 5 minutes from power-
save mode
Dimensions approx. 325 mm x 250 mm x
55/185 mm (W x H x D)
Weight (without keypad) 6.9kg
CE marking Electromagnetic compatibility
Low Voltage Directive
