Dräger Fabius GS premium - Electrical Safety; External Fresh-Gas Outlet; Fuses

Technical data
190 Instructions for use Fabius GS premium SW 3.n
Fuses
External fresh-gas outlet
Electrical safety
Dimensions W x H x D
With trolley, compact breathing system, and mount
for 3 vaporizers
1)
103.5 x 132 x 84 cm (40.7 x 52 x 33 in)
With trolley, compact breathing system, and mount
for 2 vaporizers
1)
76 x 132 x 84 cm (30 x 52 x 33 in)
1) Width varies depending on the position of the breathing system, arm
Main fuses For 100 to 240 V power supply
2x T2.5AH 250 V IEC 60127-2/V
Size: Length 20 mm, ø5 mm (glass 4.4 mm)
Battery fuse 1x T3.15AH 250 V IEC 60127-2/V
Size: Length 20 mm, ø5 mm (glass 4.4 mm)
Connection 22 mm outer taper / 15 mm inner taper (ISO)
Pressure limitation Max. 80 cmH
2O (hPa) at 18 L/min
Fresh-gas flow 0 and 0.2 to 18 L/min
In compliance with UL 60601-1
IEC 60601-1
CAN/CSA C22.2 No. 601.1-M90
