HBSPS Technical DataSupplement
HBSPS Technical Data
The Fabius can be configured with a heated breathing system to reduce condensation of
moisture in the system.
Electrical
AC Input Voltage and Current
100-240 VAC, 50-60 Hz nominal, single phase, 0.6 Amps max.
DC Output
15Vdc ± 5%, 1.3 Amps
Fuses
• 2x T2.5AH 250V IEC 60127-2/V
• 1x F1.60AH 250V IEC 60127-2/V
Electromagnetic Compatibility (EMC)
Conforming to EN 60601-1-2, IEC 60601-1-2, and ANSI/AAMI/IEC 60601-1-2
Electrical Safety Conformance
• IEC 60601-1
• CAN/CSA C22.2 No. 601.1-M90
• UL 60601-1
Environmental
Temperature
Operating +10 °C to +35 °C
Storage -10 °C to +70 °C
Humidity
Operating 20% to 80% non-condensing
Storage 10% to 90% non-condensing
Barometric Pressure
Operating 700 to 1060 mbar
Storage 500 to 1060 mbar
16 Supplement #9038278, Rev. 07 Fabius GS/GS premium/Tiro/OS Supplement
