Dräger Flame 3000
7 Technical data
7.1 Electrical specication
7.1.1 Power supply
Supply voltage: 18 – 30 Vdc (24 Vdc
nominal) including ripple
Supply ripple: 1 Vpk-pk
Power consumption: 6 W
Shutdown voltage
(low supply): < 17 Vdc
7.2 Mechanical specication
7.2.1 Enclosure
Enclosure material: Aluminum alloy grade HE30
or stainless steel 316
Finish: Epoxy coated nish;
Dräger blue
Weight: Aluminum; 2.5 kg (5.5 lb)
stainless steel;
5.5 kg (12.1 lb)
Dimensions: 220 mm × 100 mm
(8.7 in. × 3.9 in)
Cable entries: M20, M25, 1/2 " or 3/4 "NPT
(single entries)
Terminal wire size: 2.5 mm
2
(14 AWG)
Ingress protection: IP66 (NEMA 4X)
7.2.2 Mounting bracket
Support xings: M8 (quantity 2)
Vertical adjustment: 0 – 45 degrees
Horizontal adjustment: ± 45 degrees
7.3 Environmental specication
Operation ambient temperature: - 60 to + 85 °C
(-76 to + 185 °F)
Storage ambient temperature: - 60 to + 85 °C
(-76 to + 185 °F)
Relative humidity: 0 – 90 % (non-condensing)
7.4 Operating specication
Detector range (depth of eld): 0 – 60 m (0 – 200 ft)
Horizontal eld of view: 120 degrees
Vertical eld of view: 80 degrees
Detector response time: 10 – 30 seconds
Power on reset delay: 5 seconds
