Dräger Infinity Acute Care System M540 - Nellcor Oximax

Instructions for use Infinity Acute Care System – Infinity M540 SW VG4.n 331
Technical data
Pulse oximetry (SpO2) Infinity MCable – Nellcor OxiMax
Adult and pediatric sensors OxiMax MaxA, OxiMax MaxAL, OxiMax MaxA, OxiMax
MaxP, OxiMax MaxN, OxiMax MaxI, OxiMax MaxR, OxiMax
MaxFast, SoftCare SC-A, OxiCliq A, OxiCliq P, OxiBandOXI-
A/N, OxiBandOXI-P/I, Durasensor DS-100A, Dura-Y D-YS
Neonatal sensors OxiMax MaxN, OxiMax MaxI, SoftCare SC-NEO, SoftCare
SC-PR, OxiCliq I, OxiCliq N, Oxi-A/N, Oxi-P/I
Parameter display Pulse oximetry (SpO2), pulse rate (PLS)
Measuring method Absorption-spectrophotometry
Measurement range SpO2: 1 to 100 %
PLS: 26 to 239 bpm
Resolution SpO2: 1 %
PLS: 1 bpm
Update interval 2s, ±0.5 s
Maximum update interval 30 s
SpO2 measuring accuracy
adult, pediatric
1) 2)
0 to 60 % not specified
60 to 80 % not specified: SoftCare SC-A, OxiMax MaxR, Ox-
iCliq A, OxiCliq P, OxiCliq N, OxiCliq I, D-YS, DS100A, Oxi-
A/N, Oxi-P/I
60 to 80%, ±3 % for: OxiMax MaxA, OxiMax MaxAL, OxiMax
MaxP, OxiMax MaxN, OxiMax MaxI, OxiMax MaxFast
70 to 100 %
±2 % for: OxiMax MaxA, OxiMax MaxAL, OxiMax MaxP,
OxiMax MaxN, OxiMax MaxI, OxiMax MaxFast,
SoftCare SC-A
±2.5 % for: OxiCliq A, OxiCliq P, OxiCliq N, OxiCliq I
±3 % for: D-YS, DS100A, Oxi-A/N, Oxi-P/I
±3.5 % for: D-YS with D-YSE Ear Clip or D-YSPD Spot Clip
80 to 100 %, ±3.5 % for: OxiMax MaxR
