English
22 Instructions for use VarioLux
Technical data of the VarioLux examination light
Ambient conditions
During operation
Temperature 10 °C to 40 °C
(50 °F to 104 °F)
Ambient pressure 700 hPa to 1060 hPa
(10.2 psi to 15.4 psi)
Relative humidity 10 % to 95 % (no condensation)
During storage
1)
and transport
Temperature –20 °C to 60 °C
(–4 °F to 140 °F)
Ambient pressure 500 hPa to 1060 hPa
(7.3 psi to 15.4 psi)
Relative humidity 10 % to 95 % (no condensation)
Photometric data
Maximum central illuminance
Ec
2)
30000 lx
Light field diameter at
0.5 m (19.7 in) distance
d10 200 mm (7.9 in)
d50 90mm(3.5in)
Color rendering index Ra (at
3500 K)
96
Color rendering index R9
(at
3500 K)
89
Setting the illuminance (5 lev-
els)
Level 1 6500 lx
Level 2 12000 lx
Level 3 18000 lx
Level 4 24000 lx
Level 5 30000 lx
Adjusting the color tempera-
ture (3 levels)
Cold white (blue) 4700 K ±2 %
Neutral white (white) 4100 K ±2%
Warm white (red) 3500 K ±2%
Maximum radiant output at
0.5 m (19.7 in) distance
105 W/m
2
Bulbs LEDs
Service life of the LED bulbs
>50000 hours
Changing the LED bulbs Not possible
Electrical data
Nominal voltage 100 V~ to 240 V~
Frequency range 50/60 Hz
Effective power (P) <18 W
Apparent power (S) 8.3 VA to 12.3 VA
Physical data
Dimensions (mm)
Weight 1.5 kg (3.3 Ib)
Classifications
Protection class acc. to
IEC 60601-1
Protection class II
Degree of protection IP 20
Electrical safety testing and
electromagnetic compatibility
according to
IEC 60601-1
IEC 60601-2-41
IEC 60601-1-2
Operating mode Continuous operation
Classification Medical Device
Europe
Class I
UMDNS code
(Universal Medical Device No-
menclature System)
12-347
GMDN code
(Global Medical Device No-
menclature)
12276
1) Storage only in closed or roofed rooms
2) 0.5 m (19.7 in) distance to the light exit point and a color temperature of
4400 K
60
163
110
140
360°
550
60
37
90°
75°
150°
460
90°
