♦ Data Tag Reference RW82VHA Cart Assembly Part Numbers:
8201081 (MU12014) Cart Assembly, VHA, 240V, UK
8201180 (MU12041) Cart Assembly, VHA, Vari-tilt, 230V
8201182 (MU12043) Cart Assembly, VHA, Vari-tilt, 240V, No Resuscitation
Auxiliary Supply Pressure Limit (81 400 80T/
MU11373)
40 cm H
2
O (3.9 kPa) ± 10% maximum
Auxiliary Flow Circuit Flow Range 0 LPM to 15 LPM
Auxiliary Flow Circuit Pressure 40 cm H
2
O (3.9 kPa) ± 10% maximum
AutoBreath™ Infant Resuscitator feature
(Factory Installed Option)
(not available in the U.S.)
I:E Ratio Fixed at 1:2 ± 20%
PEEP 0 to 18 cm H
2
O (0 to 1.77 kPa) ± 10%
Adjustable breath rate range 18 to 60 BPM ± 10% of setting
Adjustable Airway Pressure Relief (range of
working pressure)
0 to 50 ± 5 cm H
2
O (4.9 ± 0.5 kPa)
Fixed Maximum Pressure
(P Lim max)
50 cm H
2
O ± 10% (5.0 kPa ± 10%)
Fixed Minimum Pressure
(P Lim min)
0 kPa
Gas Supply, O2 consumption 5 LPM
System oxygen consumption 50 LPM maximum
Suction
Suction Circuit Adjustable Suction Intensity 0 kPa (0 mm Hg) to 19.99 kPa (150 mm Hg)
± 0.53 kPa (3.98 mm Hg)
Suction Circuit Maximum Vacuum -19.99 kPa (-2.90 psi) ± 0.53 kPa (0.08 psi)
Suction Circuit Maximum Flow Rate < 20 LPM (minimum of 16 LPM at maximum)
NOTE:
Suction will be driven by a 20 psi regulated
100% O
2
source.
Tubing 6 mm (0.25") inner diameter by 1.8 m (6') with
sure-grip female molded connector
Total Flow Resistance (without attachments,
subassemblies, or components added to the
breathing system)
≤ 2 cm H
2
O @ 15 LPM
Total Flow Resistance (with attachments, sub-
assemblies, or components added to the breath-
ing system)
≤ 6 cm H
2
O @ 5 LPM
Blender Module Oxygen Concentration,
Adjustable
21 O
2
% - 100 O
2
%
