5 - 9
Name Description
Suction gauge Displays the suction level from 0 mm Hg (0"H
2
O) to 200 mm Hg
(107"H
2
O) of vacuum.
Suction control Adjusts the suction level from 0 mm Hg (0"H
2
O) to 150 mm Hg
(80"H
2
O).
Suction On/Off switch Turns the suction on and off. (Gas supply must be turned on.)
Primary Outlet Accepts the primary gas tubing. If the blender option is installed,
it delivers blended gas. Otherwise, it delivers 100% oxygen.
Flow Rate (LPM) control Adjusts the patient gas flow from 0 LPM to 15 LPM.
Airway Pressure port Provides a connection for the airway pressure gauge to the patient
breathing circuit.
Airway Pressure gauge (only works
with Primary Flow)
Displays the airway pressure from -1 kPa (-10 cm H
2
O) to 8 kPa
(80 cm H
2
O).
Aux Outlet 100% oxygen
connector
Connection for the auxiliary gas delivery line at the hose barb
connection on the front panel. Provides 100% oxygen only. Use
tubing with an inner diameter of 0.25" (0.64 cm).
Aux Flow (LPM) control Adjusts the auxiliary patient gas flow from 0 LPM to 15 LPM.
